IP67 High Accuracy Servo Stabilized Platform EO/IR Targeting System DC24～36V
JH240-2 EO/IR Gimbal is applicable on small and medium-sized ship for stable target observation, search, tracking, aiming and aerial warning, etc. The IR optical system with continuous zoom is combined with the complex variable control system, the 2-axis stabilized platform combined with high accuracy gyro and servo control system. The calibration ensures the optical axes alignment of IR camera, daylight camera and laser range finder, which guarantees the high accuracy of the system stabilization and tracking.
Features
-
Daylight camera with 30× continuous zoom
-
IR camera with 80mm focal length
-
4.5km laser range finder
-
Manual/auto tracking
Technical Specification
| SYSTEM PARAMETER |
| Stabilization platform | 2-axis |
| Range | Azimuth:360°continuous |
| Elevation:-90°～+90° |
| Max. angular speed | Azimuth:≥60°/s |
| Elevation:≥60°/s |
| Random error of angular report accuracy | ≤0.1° |
| Stabilization accuracy | ≤0.5mrad |
| IP grade | IP67 |
| External interface | Power supply:DC24～36V |
| Communication:Async RS422/RS232 |
| Video:HD-SDI/sync RS422/ network |
| IR CAMERA |
| Detector | Uncooled FPA |
| Resolution | 640×512 |
| Pixel size | 17μm×17μm |
| Spectral band | 8μm～14μm |
| Focal length | 80mm |
| FOV | 7.79°～6.23° |
| DAYLIGHT CAMERA |
| Sensor | 1/2.8’’ CMOS |
| Resolution | 1920×1080 |
| Optical zoom | 30× |
| Focal length | 4.3mm~129mm |
| FOV | 63.7°～2.3° |
| LASER RANGE FINDER |
| Wavelength | 1550nm |
| Divergence angle | 10mrad |
| Range | 5m～4.5km |
| Accuracy | ±3m(50～1500m),±5m(1500～4500m) |
| PHYSICAL PARAMETER |
| Dimension | Φ240×365mm |
| Weight | ≤11kg |
| Color | navy gray |
| ENVIRONMENTAL PARAMETER |
| Operating temperature | ﹣20℃～﹢60℃ |
| Storage temperature | ﹣30℃～﹢70℃ |
